STL-G5-N2 – Nitrogen Tyre Inflation System for Cars & LCV’s

SARV’s Nitrogen Tyre Inflation System
Filters nitrogen effectively from the air to fill the tyres.
Semi-automatic operation for car and light truck tire inflation.
Nitrogen stays in the tyre longer than the air, hence maintains tyre pressure for a longer time.
Keeps the tyres cooler.
Auto-start inflation
Single tire application
Nitrogen purge (N2P)
90PSI/6.2Bar/620kPa
58L/min(2.0cfm)
Connect to an air compressor for Air source.

Parameter/ Model	UoM	G5-N₂
Nitrogen Purity	%	95 - 99+%
Required Input Pressure	Kg/cm²	12-14
N₂ Filling Range	psi	0-90
Pre Filter	Micron	5
Outlet Air Pressure	Kg/cm²	10-12
Nitrog. Storage Tank Including External	Liters	118
Power Supply	VAC	230/1 ph/50 ±/10v
Net Weight	Kgs	89
Overall Dimensions	mm	1255 x 720 x 435
